PEN 55V

Air Drones (UAV/UAS)

Description

The PEN 55V is a heavy-lift VTOL UAV system designed for multi-mission operations with 55kg maximum takeoff weight and 15kg payload capacity. It features fully automatic control, no runway requirement, easy deployment and maintenance, large autonomy, and low detectability. Powered by a 10kW turbine engine using Jet A1, TS-1, T2, or RT fuels, it offers 2.5+ hours endurance, speeds up to 110 km/h, and operates up to 10,000 ft altitude with datalink ranges up to 100km standard or SATCOM optional.

About the Company

Pen Aviation

Pen Aviation is a comprehensive aviation solutions provider offering services in private jet, helicopter, seaplane, and professional UAV domains. They provide aircraft sales, charter, consulting, i...

Videos

External Video

Watch Video

Core Information

Product class
Defense Enterprise Industrial
Platform category
VTOL Fixed-wing
Rotor configuration
Not applicable
Primary use cases
Surveying/Mapping Inspection Defense/ISR Public Safety/Search & Rescue Delivery/Logistics Environmental Monitoring Agriculture
Name
PEN 55V
Release status
In production

Performance & Dimensions

Length (mm)
2640
Endurance (minutes)
150
Max speed (km/h)
110
Height (mm)
600
Max payload (kg)
15
Service ceiling (m)
3048
Empty weight (kg)
25
Width (mm)
480
Max takeoff weight (MTOW) (kg)
55

Airframe & Propulsion

Frame materials
Carbon fiber
Propulsion type
Gasoline/Petrol (ICE)
Battery chemistry
None/Not applicable

Payload & Interfaces

Payload interfaces/mounts
Bottom mount
Supported gimbal size
Not specified

Avionics, Navigation & Autonomy

Autopilot features
Waypoint missions Auto takeoff/landing Return-to-home (RTH)
GNSS systems
GPS
RTK/PPK support
None
Obstacle avoidance sensors
None
Flight controller platform
Proprietary

Communications & Control

Control link types
SATCOM
Encryption standard
Not disclosed
Ground control compatibility
Proprietary GCS
Video downlink type
Other
Video downlink resolution
Not specified
Control link range (km)
100

Operational Capabilities

Operating environments
Urban Rural Mountainous Maritime
Takeoff/landing methods
VTOL
BVLOS ready
VTOL capable

Environmental & Durability

IP rating
None/Not specified

Safety

Parachute system
None

Compliance & Certification

Export control status
Not specified
EASA class marking
None/Unmarked
Remote ID compliance
Not specified

Logistics & Commercial

Included in box
Aircraft
Price notes
Configuration-dependent pricing
Shipping restrictions
Export controlled
Optional accessories
SATCOM datalink
Availability status
In stock
